Intermec EasyCoder PC4 Programmer's Reference Manual

Chapter 5 — Editing in Direct Mode
ESim for the PC4 and PF8 Printer Programmer’s Reference Manual 27
Place Variable Text
The next line is a text line, using text size 5 in reverse and prints
the variable V00. The data printed in this field must be sent to
the printer at the time of form retrieval.
Place a Combination of Fixed Data and a Variable
The following two command lines consist of a combination of
fixed data enclosed in quotation marks and variable data.
Place a Combination of Fixed Data and a Counter
The next command line is a text line containing fixed data and
the counter (C0). The first time this label form is retrieved for
printing, the start value for this counter must be sent to the
printer. The printer stores the value of the counter for this form
and automatically continues to print the next value the next time
this form is retrieved. Reset or set to another value by sending a
new start value.
Command Explanation
A24,160,0,5,1,1,R,V00  Write a text line, first variable.
Command Explanation
A24,250,0,4,1,1,N,“MODEL:”V01  Write a text line, second variable.
A472,312,0,4,1,1,N,”Checked by:“V02  Write a text line, third variable.
Note: The value of the counter is kept in the memory even if
another form is retrieved or the printer is switched off.
Command Explanation
A24,312,0,4,1,1,N,“SERIAL#:“C0”  Write a text line with fixed data and first
counter.

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
