Remarks: Gaps and Slots
The printers have a label gap sensor designed to detect the top of
each form:
•through the semi-transparent liner in the gap between labels.
• through a hole in the media.
The sensor is located slightly to the right in relation to the center
of the media path (as seen from the front of the printer). Refer to
your printer user's manual for specifications of the size and
location of detection slots.
When entering Dump mode, or when printing a form for the
first time after power-up using the Windows Driver, the printer
automatically determines the Q value while feeding a couple of
labels. The current Q value is printed on the test label and the
label produced by a U command. For more information on
Dump Mode, see “Dump Mode” on page 4.
Q Command Parameter Descriptions
Parameter Description
p
1
Form length measured in dots.
203.2 dpi (8 dots/mm):
Default is 1200 dots.
Maximum without memory cartridge is 3780 dots
at full print width.
Maximum with 256k SRAM cartridge is 6258
dots at full print width.
300 dpi (11.81 dots/mm):
Default is 1200 dots.
Maximum without memory cartridge is 2640 dots
at full print width.
Maximum with 256k SRAM cartridge is 4364
dots at full print width.
p
2
Gap length measured in dots.
203.2 dpi (8 dots/mm) at 24 dots is the default.
300 dpi (11.81 dots/mm) at 24 dots is the default.
±p
3
Optional offset length measured in dots.
