Intermec EasyCoder PC4 Programmer's Reference Manual

Chapter 7 — Commands
ESim for the PC4 and PF8 Printer Programmer’s Reference Manual 101
Example 2:
Butterfly label (293.2 dpi = 8 dots/mm printhead):
p
1
= 12.5 mm (100 dots)
p
2
= 3.0 mm (24 dots)
p
3
= 3.0 mm (24 dots)
The Q command would be:
Q100,24+24 
Q - Set Form Length (Black Mark)
This command is used switch from label gap sensor to the black
mark sensor, and to specify the location and height of the black
marks on the back of the media.
Syntax: Qp
1
,Bp
2
[±p
3
]
.
p
p
p
PRINT
DIRECTION
1
2
3
Q Command Parameter Descriptions
Parameter Description
p
1
Distance between black marks measured in dots.
B Disables label gap sensor and enables the black
mark sensor.
p
2
Height of black mark measured in dots.
±p
3
Optional offset length measured in dots.

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
