Intermec EasyCoder PC4 Programmer's Reference Manual

Chapter 7 — Commands
72 ESim for the PC4 and PF8 Printer Programmer’s Reference Manual
.
Remarks: When using labels on liner, the printer advances each printed
label to the cutting position (between two labels) according to the
program before the liner is cut. Due to differences between
batches of media, the printer may not cut exactly between labels,
but either cut a slice at the last part of the printed label or a slice
at the front part of next label.
Cutting through labels should be avoided because the adhesive
may stick to the cutting parts and prevent them from operating
properly.
If the cut occurs in the already printed label, increase the cut
position index value.
If the cut occurs in the next label, decrease the cut index value.
Example:
To increase the cut position index value, enter the command
below:
f110 
FE - End Store Command
Purpose: This command is used to end a Form Store sequence.
Syntax: FE
Remarks: The Form Store sequence must start with the FS command and
end with the FE command.
f Command Parameter Descriptions
Parameter Description
p
1
Cut position index measured in dots:
203.2 dpi (8 dots/mm):
Recommended: 070 - 130
Minimum/Maximum: 020 - 180
Default is 100
300 dpi (11.81 dots/mm):
Recommended: 050- 150
Minimum/Maximum: 000 - 200
Default is 100

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
