Intermec EasyCoder PC4 Programmer's Reference Manual

Chapter 7 — Commands
ESim for the PC4 and PF8 Printer Programmer’s Reference Manual 103
Example 2:
On the tag below, the black marks are printed between the
perforations. The printer has a 203.2 dpi (8 dots/mm) printhead.
p
1
= 31 mm (248 dots)
p
2
= 7.0 mm (56 dots)
p
3
= 17 mm (136 dots)
The Q command would be:
Q248,B56-136 
q - Set Label Width
Purpose: This command is used to set the label width when using less than
full width labels.
Syntax: qp
1
.
p
3
p
2
p
1
Perforation
q Command Parameter Descriptions
Parameter Description
p
1
Width of label measured in dots.
Default:
832 at 203.dpi (8 dots/mm)
1208 at 300 dpi (11.81 dots/mm)

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
