Intermec EasyCoder PC4 Programmer's Reference Manual

Chapter 7 — Commands
ESim for the PC4 and PF8 Printer Programmer’s Reference Manual 63
C - Cut Immediate
Purpose: This command is used to make the cutter perform a cutting cycle
without printing a form.
Syntax: C
Remarks: The command C is used for two purposes. C appended by
parameters is used to define counters in the Form Edit mode,
whereas C without any appending parameters is used to initiate a
cutting operation.
C (Cut Immediate) cannot be used inside a form or in
connection with a the Keyboard display unit.
To perform self-cleaning of the cutter blade, issue five
consecutive C commands without any media loaded.
Example:
To perform a cutting cycle, enter the command below:
C 
D - Density
Purpose: This command is used to select the print density.
Syntax: Dp
1
Remarks: The density command is used to control the energy to the
printhead. A number of factors affect the actual darkness of the
printout:
• Direct thermal printing or thermal transfer printing.
•Print speed.
• Different brands of direct thermal media.
• Different combination between transfer ribbons and receiving
face materials.
D- Density Parameter Descriptions
Parameter Description
p
1
Density settings (0-15). Default is 10.
0 is the lightest printing and 15 is the darkest.

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
