Intermec EasyCoder PC4 Programmer's Reference Manual

Chapter 7 — Commands
ESim for the PC4 and PF8 Printer Programmer’s Reference Manual 121
A50,150,0,3,1,1,N,"TEXT"V02":Center justified" 
A50,200,0,3,1,1,N,"TEXT"V03":No justification" 
FE 
Refer to the ? command for a continuation of this example.
W - Windows Mode
Purpose: This command is used to enable/disable the Windows command
mode (special applications only).
Syntax: Wp
1
.
Remarks: When enabled, the printer accepts Windows mode escape
sequences to print data. When disabled, escape sequences are
ignored up to the next linefeed.
The Windows mode escape sequences are only used by the
Windows Printer Driver. When working with a mainframe or
other non-Windows host, this mode can be disabled to prevent
erratic operation.
X - Draw Box
Purpose: This command is used to draw a box shape.
Syntax: Xp
1
,p2,p3,p4,p5
.
W Command Parameter Descriptions
Parameter Description
p
1
Windows mode enable/disable:
Y = Enables Windows mode.
N = Disables Windows mode (default).
X Command Parameter Descriptions
Parameter Description
p
1
Horizontal start position (X) in dots.
p
2
Vertical start position (Y) in dots.
p
3
Line thickness in dots.
p
4
Horizontal end position (X) in dots.
p
5
Vertical end position (X) in dots.

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
