Intermec EasyCoder PC4 Programmer's Reference Manual

Chapter 7 — Commands
ESim for the PC4 and PF8 Printer Programmer’s Reference Manual 107
Example:
This example creates a 50 dot left margin and a 100 dot top
margin from the label edge set by q command.
r50,100 
S - Speed Select
Purpose: This command is used to select the print speed.
Syntax: Sp
1
.
Remarks: Changing the print speed can affect the blackness of the printout,
which may have to be adjusted using a D command. The density
settings has priority over speed selection, which might cause the
speed to be reduced at high density settings.
Example:
This example shows how to set the print speed to 500 mm/sec
(2 in/sec).
S2 
S Command Parameter Descriptions
Parameter Description Notes
p
1
Speed select value:
0 = 30 mm/sec (1.2 in/sec). Available for 300 dpi (11.81
dots/mm) printheads only.
1 = 40 mm/sec (1.6 in/sec). Available for 300 dpi (11.81
dots/mm) printheads only.
2 = 50 mm/sec (2 in/sec). Available for both 203.2 dpi
and 300 dpi printheads.
3 = 75 mm/sec (3 in/sec). Available for 203.2 dpi (8
dots/mm) printheads only.
4 = 100 mm/sec (4 in/sec). Available for 203.2 dpi (8
dots/mm) printheads only.

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
