Intermec EasyCoder PC4 Programmer's Reference Manual

Chapter 7 — Commands
56 ESim for the PC4 and PF8 Printer Programmer’s Reference Manual
Masking (Intrinsic)
This enables the ratio of dark to light modules in the symbol to b
approximated to 1:1 whilst minimizing the occurrence of
arrangements of close modules which would prevent efficient
decoding.
The QR bar code specific options should append the general part
of the two-dimensional bar code command (indicated by the
italicized characters, see “b - Two-Dimensional Bar Codes,
General Part” on page 48 for more information.
Syntax: bp
1
, p
2
, p
3
,[cn,mn,on,sn,xn,ynn],“DATA”
.
Masking Parameter Descriptions
Parameter Description
c Fixed data mode character set:
1 = Numerical data mode
2 = Alphanumerical data mode
3 = 8-bit data mode (JIS 0201)
4 = Kanji data mode (JIS 0208)
5 = Mixing mode (any of mode c1-c4, model
type 2)
Model 1 default = Most optimal alternative of c1
to c4.
Model 2 default = c5.
Internally during rendering the QR Code, the
mode can be switched within a bar code to
minimize the bit stream area. By using parameter
cn, the data mode character set is fixed.
m Model type is defined and unchanged within one
QR Code.
1 = Original version
2 = Enhanced version (recommended). Default.

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
