Intermec EasyCoder PC4 Programmer's Reference Manual

Chapter 7 — Commands
46 ESim for the PC4 and PF8 Printer Programmer’s Reference Manual
After retrieving and printing the form, the label may look like
this:
Combination of several options can be used, for example:
B50,300,0,3,1,2,50,B,“Deluxe”V01C2“Combo” 
This example writes a Code 39 bar code containing the
information “Deluxe”, the contents of variable 01, the contents
of counter 2, the text “Combo”, and the contents of variable 01.
Bar Code 128 Family
The Code 128 family has three unique data character subsets: A,
B and C. The choice of data character subset depends on the start
character representing code A, B or C. The code subset can be
redefined within the symbol by code set control characters A, B
or C, or shift. In addition, a set of special functions are available
via FNC1, FNC2, FNC3 and FNC4. All these can be invoked in
the data field. The human readable part in the symbol, FNC and
code subset control characters is represented by a space. The
input data string is a fixed string of maximum 64
alpha-numerical characters.
Code 128 With Auto Selection of Subset and UCC/EAN
Code 128 and EAN128 use automatic subset selection of Subset
A, B, or C, both at the start and within the bar code.

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
