Intermec EasyCoder PC4 Programmer's Reference Manual

Chapter 7 — Commands
ESim for the PC4 and PF8 Printer Programmer’s Reference Manual 75
Example:
This example begins the form store sequence of TEST1 and the
ends it.
FS“TEST1” 
.....
FE 
Startup Form
A special case of forms is the startup form, that is automatically
retrieved and prompted for variables (if necessary) each time
power is applied to the printer. A startup form is created by
naming the form "AUTOFR". To exit the "AUTOFR" mode,
send XOFF or NULL to the printer on the serial interface.
Always test the form using another name before making it a
startup form. If a startup form causes an error, there are two ways
of clearing it:
• If the indicator lamp shines green, send XOFF or NULL to
exit “AUTOFR” mode. Then delete the startup file using
FK“AUTOFR”.
• If the indicator lamp shines orange, there is no
communication and the memory must be erased by pressing
the Feed key for more than 3 seconds in Dump mode.
GG - Print Graphics
Purpose: This command is used to print a graphic that has been previously
stored in memory.
Syntax: GGp
1
,p
2
,“name”
.
GG Command Parameter Descriptions
Parameter Description
p
1
Horizontal start position (X) in dots.
p
2
Vertical start position (Y) in dots.
“name” This is the name used when the graphic was
stored. The name may be from 1 to 8 characters.
The printer is case sensitive, so the use of upper
and lowercase letters must match the original
name.

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
