Intermec EasyCoder PC4 Programmer's Reference Manual

Chapter 7 — Commands
98 ESim for the PC4 and PF8 Printer Programmer’s Reference Manual
.
Remarks: Media feeding is disrupted by pressing the Feed key or by
opening the cover.
Example 1:
The following command feeds the media forward 360 steps,
make the printer detect a gap/black mark before the next print
job, and cause a delay of 3 seconds after the feed. The red LED
blinks during the delay.
PF360,0,30 
Example 2:
The following command retracts the media 360 steps and assume
that the media is in printing position.
PF-360,1 
Q - Set Form Length (Gap or Slot)
Purpose: This command is used to set the form and gap length when using
the label gap sensor, or the amount of media feed after the print
image in case of continuous stock.
Syntax: Qp1,p2[±p3]
PF Command Parameter Descriptions
Parameter Description
p
1
Number of steps to feed the media. Positive values feed
the media forward, negative values backward. Range is -
999 to 9999.
p
2
Position control after feeding. Allowed values:
0 = The media has unknown position. Printer needs
label gap/black mark detecting before next print job
(default).
1 = Media is located in the printing position.
2 = Media feed stops when Black mark/label gap is in
sensor position or, if no black mark/gap is detected,
when p
1
dots are stepped (error 99 is reported).
p
3
Option delay after feeding. Delay is p
3
*100 ms.

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
