Intermec EasyCoder PC4 Programmer's Reference Manual

Chapter 7 — Commands
ESim for the PC4 and PF8 Printer Programmer’s Reference Manual 119
USR - Read Serial Number
Purpose: This command is used to read the serial number in EEPROM.
Syntax: USR
UV - Product Identity and Asian Font Types
Purpose: This command generates output on the RS-232 or USB port
about the software and fonts stored in the memory cartridge.
Syntax: UV
Remarks: The first line returned after the UV command is base software
appended by a CR/LF, the next is one line with information on
the font appended by CR/LF.
V - Define Variable
Purpose: This command is used to define variable data fields for use in
stored forms.
Syntax: Vp
1
,p
2
,p
3
,“PROMPT”.
Note: This command can only be used on PF8 printers.
V Command Parameter Descriptions
Parameter Description
p
1
Variable reference number (00-99).
A maximum total of 1500 bytes of data for all variables is
allowed.
p
2
Maximum number of digits for the variable
(1-99).
A maximum total of 1500 bytes of data for all variables is
allowed.
p
3
Field justification:
L = Left justification.
R = Right justification.
C = Center justification.
N = No justification.
[-] A single leading minus sign in the prompt field causes
the prompt to be sent one time only after the form is
retrieved (Keyboard Display Unit only).

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
