Intermec EasyCoder PC4 Programmer's Reference Manual

Chapter 7 — Commands
100 ESim for the PC4 and PF8 Printer Programmer’s Reference Manual
Continuous Stock
In case of continuous stock, parameter p
1
decides the amount of
media feed performed after the actual print image has been
printed. Continuous stock is selected by setting parameter p
2
= 0.
Be careful not having the printer loaded with continuous stock
when entering Dump mode or an error occurs.
Example 1:
Rectangular label (203.2 dpi = 8 dots/mm printhead):
p
1
= 20.0 mm (160 dots)
p
2
= 3.0 mm (24 dots)
The Q command would be:
Q160,24 
p
p
1
2

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
