Intermec EasyCoder PC4 Programmer's Reference Manual

Chapter 7 — Commands
ESim for the PC4 and PF8 Printer Programmer’s Reference Manual 109
SPC - Setup Print Copy
Purpose: This command is used to change the function of the Feed key to
print a copy of the label currently residing in the image buffer.
Syntax: SPCp
1
.
Remarks: The following commands disable Print Copy when SPC1 is set:
A, b, B, GW, GG, LE, LO, LS, LW, N, q, Q, r, R, X, and Info.
The current SPC value is stored in Flash memory and printed on
the test label.
Example:
This example shows how to activate Print Copy, see command
below:
SPC1 
TD - Define Date Format
Purpose: This command is used to define the date format when printing.
Syntax: TDp
1
[/p
2
/p
3
]
SPC Command Parameter Descriptions
Parameter Description
p
1
Setup Print Copy value:
0 = Media feeds as usual when the Feed key is
pressed (default).
1 = Print Copy is activated, but is disabled if the
A, b, B, GW, GG, LE, LO, LS, LW, N, q, Q,
r, R, X, and Info commands have been sent since
the last printout.
2 - Print Copy is activated. In this state, additional
fields can be added to the existing image and
printed by pressing the Feed key.

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
