Intermec EasyCoder PC4 Programmer's Reference Manual

Chapter 6 — Retrieving and Printing a Form
32 ESim for the PC4 and PF8 Printer Programmer’s Reference Manual
Example
The form “TEST” edited in the previous chapter can be retrieved
and printed from any ASCII-sending device using this sequence:
The question mark (?) following the FR command is required for
printing any fields edited in Form Edit mode that contain
variables or counters. If no question mark is transmitted, all fields
containing variable input are omitted from the printout.
Variables and counter start values must be defined, either by
programming or by user input.
Command Explanation
 CR/LF to start command structure
FR“TEST” 
Retrieve form
? 
Call for variables
EASYCODER 
Substitute variable V00
501SA 
Substitute variable V01
Dan 
Substitute variable V02
100000 
Counter start value C0
P1,2 
Print 2 copies of a single label
Note: It is critical to the syntax to send exactly the same number
of variable lines as defined for the label form.

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
