Intermec EasyCoder PC4 Programmer's Reference Manual

Chapter 7 — Commands
ESim for the PC4 and PF8 Printer Programmer’s Reference Manual 111
TS- Set Real-Time Clock
Purpose: This command is used to set the time and date in the optional
real-time clock circuit.
Syntax: TSp
1
,p
2
,p
3
,p
4
,p
5
,p
6
.
Remarks: This command works only if the printer is fitted with an optional
real-time clock circuit (RTC).
Example:
This example sets the date to JAN 15,2004 and the time to
12:45:23 p.m.
TS01,15,04,12,45,23 
U- Print Configuration (General)
Purpose: This command is used to print the current printer configuration
on a label without having to enter Dump mode.
Syntax: U
Example:
This example shows a typical label printed when using the U
command with the following setup:
• Memory cartridge loaded
• Media with black marks
• Two forms, two graphics, and five soft fonts loaded
• Short labels
TS Command Parameter Descriptions
Parameter Description
p
1
Months are entered as 0-12.
p
2
Days are entered as 01-31.
p
3
Years are entered as the last two digits. For
example 2004 is entered as 04.
p
4
Hours entered in 24 hour format (00-23).
p
5
Minutes are entered as 00-59.
p
6
Seconds are entered as 00-59.

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
