Intermec EasyCoder PC4 Programmer's Reference Manual

Chapter 7 — Commands
ESim for the PC4 and PF8 Printer Programmer’s Reference Manual 113
Parameter p
1
saves in Flash.
If command UC is activated, it replaces the <ACK> character at
the end of command US and P.
If an error occurs and error report is activated, the error message
is sent instead.
Example:
The table below shows an example of the UC command with the
a reply.
UDC - Memory Cartridge Information (PC4 only)
Purpose: This command checks an inserted memory cartridge and returns
information on its content on the RS-232 or USB channel.
Syntax: UDC
Remarks: This command checks the memory cartridge for the following
information and returns one of the following alternatives listed in
the table below.
Command Reply Explanation
UC062 
> Set Command Reply Accept
character to “>”.
US 
> Reply error.
X50,200,5,400,20 
>Draw a box.
P 
> Print box and reply “>” at ready.
Memory Cartridge Commands and Explanations
Command Explanation
NA 
Cartridge not detected.
000 
Cartridge detected, but no relevant
information is found.
001-004 
Cartridge detected. Followed by one to four
lines of information on detected firmware,
and/or Asian fonts.

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
