Intermec EasyCoder PC4 Programmer's Reference Manual

Chapter 7 — Commands
ESim for the PC4 and PF8 Printer Programmer’s Reference Manual 117
UN - Disable Error Reporting
Purpose: This command is used to disable error reporting.
Syntax: UN
Remarks: Cancels US command.
UP - Code Page and Memory Inquiry Print
Purpose: This command causes the printer to print and send the currently
selected code page, and memory status to the host through the
RS-232 or USB port.
Syntax: UP
The printer:
• sends information on the currently selected code page and
memory status back to the host (same as UM command).
• prints the current printer configuration.
The format of the data sent to the host in the following formats:
UMp
1
,p
2
,p
3
,p
4
,p
5
,p
6
,p
7
UIp
8
,p
9
,p
10
.
Remarks: Also see “I - Character Selection” on page 81, “U- Print
Configuration (General)” on page 111, and “UI - Enable
Prompts/Code Page Inquiry” on page 115.
UP Command Parameter Descriptions
Parameter Description
p
1
Image buffer size in kilobytes.
p
2
Form memory allocation size in kilobytes.
p
3
Form memory free in kilobytes.
p
4
Graphic memory allocation size in kilobytes.
p
5
Graphic memory free in kilobytes
p
6
External font memory allocation size in kilobytes.
p
7
External font memory free in kilobytes.
p
8
Number of data bits.
p
9
Code page.
p
10
Country code.

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
