Intermec EasyCoder PC4 Programmer's Reference Manual

Chapter 7 — Commands
116 ESim for the PC4 and PF8 Printer Programmer’s Reference Manual
The printer sends information on the currently selected code
page and memory status back to the host in the following
formats:
UMp
1
,p
2
,p
3
,p
4
,p
5
,p
6
p,
7
UIp
8
,p
9
,p
10
[,p
11
]
.
Remarks: Also see “I - Character Selection” on page 81, “U- Print
Configuration (General)” on page 111, “UI - Enable Prompts/
Code Page Inquiry” on page 115, and “UP - Code Page and
Memory Inquiry Print” on page 117.
Example:
This example returns the current code page:
UM 
UM1050,998.0,8.3,40,1,37,2 UI80,001,B581
UM Command Parameter Descriptions
Parameter Description
p
1
Image buffer size in kilobytes.
p
2
Total user Flash memory size for [Form + Graphic
+ External font + Asian font] in kilobytes
including decimals.
p
3
Form memory used in kilobytes. Decimals =
Forms file counter.
p
4
Graphic memory allocation size in kilobytes.
p
5
Graphic file counter.
p
6
External font memory allocation size in kilobytes.
p
7
External font file counter.
p
8
Number of data bits.
p
9
Code page.
p
10
Country code.
p
11
Asian font file flag and used memory in kilobytes,
where nnn = memory used in kilobytes for Asian
font.
Annn= Chinese traditional
Bnnn = Chinese simplified
Cnnn = Japanese
Dnnn = Korean

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
