Intermec EasyCoder PC4 Programmer's Reference Manual

Chapter 7 — Commands
78 ESim for the PC4 and PF8 Printer Programmer’s Reference Manual
To store the image in the printer connected to port LPT1, at the
DOS prompt type:
COPY STOREIT.TXT LPT1:
COPY LOGO.PCX LPT1: /b
The GI command can be used to verify that the graphic was
successfully stored. If not, check that the .PCX file is in 1-bit
(black and white) format and that the available graphics memory
is large enough to accommodate the graphics.
The following sequences show how to generate the image
“PYRAM” and print two copies. Image “PYRAM” is saved as a
PCX-file (version 2) in monochrome mode with a size of 32*32
dots. Data below is shown in hex and ASCII format:
Now the image is stored on FLASH and can be used anywhere
and several times on the printout, as this example below:
N 
GG0,0,“PYRAM” 
GG50,50,“PYRAM” 
P 
0000
0010
0020
0030
0040
0050
0060
0070
0080
0090
00A0
00B0
00C0
00D0
00E0
00F0
0100
0110
0120
0130
0D 0A 47 4D 22 50 59 52 41 4D 22 32 39 34 0D 0A
0A 02 01 01 00 00 00 00 1F 00 1F 00 0E 00 0E 00
00 00 00 FF FF FF 00 00 1D 04 00 00 00 00 00 00
38 42 13 00 EC E9 12 00 03 00 00 00 90 41 13 00
FF FF FF FF 00 00 00 00 FF FF FF FF DC E9 12 00
00 01 04 00 01 00 00 00 00 00 00 00 00 00 00 00
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
C1 FF C1 00 00 C1 FF 80 C1 FF C1 FF 01 BF 80 01
C1 FD A0 7F C1 FE 05 AF C1 C0 03 C1 F5 A8 3F C1
FC 15 AB C1 E0 07 C1 D5 AA 1F C1 F8 55 6A C1 F0
0F 56 5A 8F C1 F1 5A 56 B8 1D 6A 55 A7 C1 E5 AA
55 6C 36 AA 55 5B C1 DA AA 55 56 6A AA C1 55 55
C1 AA AA C1 55 55 C1 AA AA 55 56 6A AA 55 5B C1
DA AA 55 6C 36 AA 55 A7 C1 E5 AA 56 B8 1D 6A 5A
8F C1 F1 5A 6A C1 F0 0F 56 AA 1F C1 F8 55 AB C1
E0 07 C1 D5 A8 3F C1 FC 15 AF C1 C0 03 C1 F5 A0
7F C1 FE 05 BF 80 01 C1 FD 80 C1 FF C1 FF 01 C1
FF C1 00 00 C1 FF
..GM”PYRAM”294..
................
................
8B...........A..
................
................
................
................
................
................
..............?.
............Uj..
.VZ...ZV..jU....
Ul6.U[...UVj..UU
....UU...UVj.U[.
..Ul6.U....V..jZ
...Zj...V....U..
.....?..........
................
......
Save image
PCX-header
PCX-header
end
PCX data
PCX data end

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
