Accessing the Throttle Curve Function
H-23
Note: In each curve, the factory setting indicates INH
for points 1, 2, 4 and 5. These values are 16.5%,
33%, 66.5% and 83.5% respectively if no value
changes are made to any other points. If any of the
other points have been changed while these points
were inhibited, the inhibited points will also change
to plot a smooth curve.
If you want to keep this from happening, highlight each
point and press the Rolling Selector twice to activate
each of the points. Repeat as necessary. The values
for each of these points can then be fully adjusted by
the Rolling Selector. To inhibit the points, highlight
the desired point with the Rolling Selector, press the
Rolling Selector to open the point, then press the clear
key (CLR) to inhibit.
1. Place the transmitter switch in the ON position.
2. Press the List key simultaneously to enter the
Function Mode.
3. Roll the Rolling Selector to highlight the THRO
CURV function, then press to access.
Note: The letter/numbers directly to the right of
THRO CURV at the top left of the LCD displays the
current Flight mode switch position.
Use NORM for hover curves and 1, 2, 3, and 4 (3 and
4 optional) for stunt curves. We will concentrate on the
hovering curve during this example.
4. Move the Rolling Selector and highlight the desired
throttle point to be adjusted. Press the Rolling
Selector to open the point value, then roll the Rolling
Selector to increase and decrease the point value.
5. To set curves for flight mode switch position 1,
highlight NORM with the Selector, press, then
select ST-1 from the drop down box and repeat
steps 4 and 5.
6. To set curves for flight mode switch positions 2
through 5, repeat step 6 above.
7. To exit the Throttle Curve function, highlight the LIST
with the Selector, and press.
