Step #20 Flap Rate, Camber Mix and Camber Adjust
S-53
Many pilots prefer to have variable camber adjustment
during launch. This enables adjustments to be made at
the last minute or even during launch, based on wind and
winch (launching) conditions.
Important: The flaperon and elevator values in the
camber mix menu are based on a percentage of the
programmed flap rate. The flap rates are defaulted
to 0% from the factory, so flaperon and elevator mix
values have no effect until the flap rate values are
set. Because of this, it’s mandatory to first adjust the
flap rates before adjusting the flaperon and elevator
camber mixes. Also remember that changing the
flap rate values also affects the flaperon and elevator
camber mix.
Flaperon Mix
In
FUNC.LIST rotate the Selector until Flaprn MX is
highlighted. Press the Selector to access the Flap Rate
menu. Rotate the Selector to highlight the launch down
value then press the Selector to access this value. With
the flight mode switch in the upper launch mode, move
the left side lever to the lower most position and adjust
the down value to the desired flap position. Now, with the
flight mode switch in the upper launch mode, move the
left side lever to the uppermost position and adjust the up
value to the desired flap position. Press the LIST button
to return to the Function Mode screen.
