Monitor
S-38
To access the servo monitor, in FUNC.LIST rotate the
Selector until
MONITOR is highlighted. Press the
Selector to access the Monitor menu then press the
Selector again to access the camber digital preset
screen. To adjust the presets, move the flight mode switch
to the launch mode (up) position. Adjust the preset
positions via the flap trim, auxiliary trim and elevator
trims on the transmitter. The values will be displayed
in the screen and then will be memorized for that flight
mode. If you wish to have these preset values be fixed
(not active in flight), once the values are established
return to the Trim Step screen in the system mode and
reduce the value of the desired channel to 0. The preset
values for all flight modes will be stored and no longer
accessible with the digital trims.
