Step #37 Flap Rate, Camber Mix and Camber Adjust (continued)
Step #38 Aileron-to-Rudder Mix
S-66
Flaperon Mix Delay
The camber adjust menu allows the programming of a
delay from 0 to 2 seconds. This delay affects the flap,
flaperon and elevator presets when switching from one
flight mode to another. When inhibited, no delay occurs
and the servo immediately transitions from one preset trim
position to another when the flight modes are switched.
With a delay programmed, the transition is smooth
relative to the delay time. A break-off function is available
that can be programmed to override the delay, based on
a selected elevator stick position. For this setup, we will
program a .5 second delay for land.
In FUNC.LIST rotate the Selector until FM Delay is
highlighted. Press the Selector to access the Camber
Adjust menu. Rotate the Selector to highlight the land
delay value then press the Selector to access this value.
Rotate the Selector to adjust the value to .5s (seconds)
Press the Selector to store the value. Press the LIST
button to return to the Function Mode screen.
In
FUNC.LIST rotate the Selector until AILRUD M is
highlighted. Press the Selector to access the Aileron-
to-Rudder mix menu. Rotate the Selector to highlight
the land left value then press the Selector to access that
value. With the flight mode switch in the lower land mode,
give a full left aileron command and rotate the Selector
to achieve the desired left rudder throw. Pressing the
Selector will store the value. Now rotate the Selector to
highlight the land right value and adjust it to the desired
position. Press the LIST button to return to the Function
Mode screen.
