PROG MIX - PROGRAMMABLE MIXERS (continued)
S-30
Master Channel - (Std. Prog Mixer)
This is the Master channel that receives input from the
pilot. The default for both the Master and the Slave
channel is FPRN. The Master channel is selected by
highlighting and selecting this parameter to obtain a
list of channels and then selecting the Master channel
from the list.
There are 4 channels that appear more than once. They
are Flap, Aileron, Elevator and Rudder. Since these
channels can be influenced by Dual Rate and Exponential
settings, they are included in the list twice - once where
the D/R and EXP settings are in effect and again where
the D/R and EXP settings are ignored. The second time
they are listed, there is a special designator to indicate
that these channels can also be used as a Master while
bypassing any Dual Rate and Exponential settings that
may be associated with them. They are designated by a
“#” (pound sign) in front of the name - #FLP, #AIL, #ELE,
and #RUD. When one of these channels is selected as
the Master, all D/R, EXP and Curve settings associated
with the Master are ignored during the mixing operation.
Instead, the mixer reads only the physical position of the
stick to perform mixing.
A (+) behind the channel indicates a trim include function.
By selecting a channel with the (+), the trim lever and any
other program mixes to the master channel affects both
the master and slave channels.
