Camber Adjust
S-23
The camber adjust screen allows a delay of up to 2
seconds to be programmed to each of the 5 flight modes.
This delay affects the flap, flaperon and elevator (and
rudder and aileron if activated) presets such that when
switching from one flight mode to another the servos don’t
rapidly change to their intended preset position. A break-
off function is available for each flight mode that bypasses
the delay at a given programmed elevator stick position.
This is useful during launch when you may wish to switch
from the launch flight mode to cruise for zoom and need
the delay to be overridden. In this case, the break-off can
be set for slight down elevator in the cruise mode.
Note: In order for the camber adjustment to operate,
flight modes must be programmed in device select
and each must have different trim presets. See
Device Select Pg. S-11 and Servo Monitor pg. S-39
for more details.
To access camber adjust, in FUNC.LIST rotate the
Selector until
CAMBR ADJ is highlighted. Press the
Selector to access the Camber Adjust menu. Rotate
the Selector to highlight the launch delay value, and
then press the Selector to access this value. Rotate
the Selector to adjust the value. Values from inhibit to
2 seconds are available. To access the break-off value,
rotate the Selector to highlight the desired break-off
flight mode then press the Selector to access this value.
To access the elevator stick position, rotate the Selector
to highlight ELEV Stick then press the Selector to access
this value. Press the Selector to store the value. Press
the LIST button to return to the Function Mode screen.
