D/R & EXP – DUAL RATE AND EXPONENTIAL
S-18
Three dual and exponential rates are available and are
selectable via flight modes or selected switches. Dual and
Expo rates are independently adjustable in each direction
by moving the appropriate stick in the desired direction.
1. Highlight and select D/R & EXP in the FUNC.LIST
to obtain the D/R & EXP display. If Flight Modes
were activated earlier in the Devic.SEL function and
D/R was set to FM in the same function, there will
be 3 sets of values displayed for each channel
– Aileron, Elevator and Rudder.
2. Use the Selector to change between Aileron,
Elevator and Rudder. Then use it to set dual rate and
exponential values.
