Activating and Assigning Flight Modes (continued)
Motor Function
S-13
To activate the speed thermal flight modes, highlight
SPEED and press the Selector to select the desired
switch position.
Important: When the speed and thermal flight
modes are activated, launch and land always have
priority. Any time launch or land is selected they
will override speed, thermal or cruise. To access
speed or thermal, the launch switch must be in
the cruise position. Try selecting the various flight
modes several times while looking at the main
info screen and you’ll quickly become familiar with
the switch priority.
Note: On the main info screen, the flight mode
that is activated will be displayed on the top
center of the screen.
Note: The flight mode switch direction can be
selected when the launch mode is programmed to a
switch. Select
NORM or REV. to reverse the direction
of the launch land switch to meet your preferences.
The motor function can be assigned to operate from
several different switches, buttons or the throttle stick. In
device select, highlight
MOTO and press the Selector to
access the available switches that can be programmed to
operate the motor.
Select the desired switch by highlighting it and press
the Selector.
AIL D/R = Aileron dual rate switch
ELE D/R = Elevator dual rate switch
RUD D/R = Rudder dual rate switch
AUX4 SW = Auxiliary 4 switch
R3P SW = Right 3-position switch
L3P SW = Left 3-position switch
BTFL SW = Butterfly switch= Auxiliary 4 switch
TIME SW = Timer button
SPOI ST = Spoiler stick
Note: If dual flaps are activated, the motor function
is not assigned to a channel. It will be necessary to
use a programmable mix to mix MOTO to any open
auxiliary channel in order to operate the throttle
when dual flaps are activated. Also see Motor Hold
on page S-27 for more details.
