JR X9303 2.4 - Rev.sw - Servo Reversing

REV.SW – SERVO REVERSING
S-19
The servo reverse screen allow the direction of each servo
to be selected.
1. Highlight and select REV.SW in the FUNC.LIST to
obtain the servo reversing display.
2. Use the Selector to highlight and select those
channels that need to be reversed. Pressing
the Selector toggles the channel between
Normal and Reverse.
[REV SW.]
THR AIL ELE RUD GER FLP AX2 AX3 AX4
REV.
NORM
