ACCESS THE SYSTEM MENU
A-2
The first thing to do when setting up a new model is to
select the desired model memory. Generally an unused
model memory is selected, however, memory that already
contains data for another model may be used, as long
as data for that model is no longer required because any
data in that memory will be lost.
1. In the SYSTEM Menu, highlight and select Model
SEL using the Selector. The currently selected model
number is displayed. If a different model is to be
selected, highlight and select the displayed model and
a list of models will appear. Scroll up and down the list
using the Selector.
2. Use the Selector to highlight and select the desired
model memory.
3. Return to the SYSTEM Menu by pressing the LIST button.
1. The System menu [SYSTEM M.] is obtained by
holding down the ENT button while turning the
transmitter on.
SELECT A MODEL MEMORY
INFO-DISP
Model SEL
MDL Name
Type SEL
MDL Reset
TRANSFER
TRIM STEP
Devic. SEL
Wing TYPE
[SYSTEM M.]
Select
MODEL 2 ACRO
[Model SEL]
Select
1 GLID
MODEL 2 MODEL 2 ACRO
3 ACRO
4 GLID
[Model SEL]
