Dual Channels (Wing Type)
V-tail (Wing Type)
A-14
1. To assign a 2nd channel to Ailerons, Elevator, Rudder
or Flaps, highlight and select INH under the desired
channel on the Mate line of the Wing TYPE display
and a list of available channels is displayed.
Note: Channels/Switches must be inhibited (INH) in
the Devic. SEL function before they will appear in
the list as an option to be used as a Dual channel.
1. If the aircraft has a V-tail configuration, highlight INH
next to V-tail in the Wing TYPE function and press the
Selector until ACT appears. Plug the right Elevator
servo into the Elevator channel (Ch3) and plug the left
Elevator servo into the Rudder channel (Ch4). Pressing
the Selector toggles the parameter between ACT and
INH. If the aircraft has a normal tail, make sure INH
is selected and plug the Elevator and Rudder servos
into the Elevator and Rudder channels (Ch3 and Ch4
respectively). Continue with Dual Channels below.
Note: To properly set the servo direction when using
the V-tail setting, begin by using servo reversing
on each channel as necessary to get the elevators
to move the proper direction with rudder stick
movement. Then if the elevators move the incorrect
direction with elevator stick movement, swap the
channels that the servos are plugged into in the
receiver to reverse them.
