WING Parameter – (Wing Type) (continued)
A-13
4. If the aircraft is a Delta wing configuration, highlight
and select Wing using the Selector and then
highlight and select DELTA as the wing type. Plug the
right Aileron into the Aileron channel (Ch2) and plug
the left Aileron into the Elevator channel (Ch3) of the
receiver.
Note: To properly set the servo direction when
using the delta wing setting, begin by using servo
reversing on each channel as necessary to get the
ailerons to move the proper direction with aileron
stick movement. If then the ailerons move the
incorrect direction with elevator stick movement,
swap the channels that the servos are plugged into
the receiver to reverse them.
