Step #23 Cruise Pre-sets
Step #24 Dual Rate and Exponential
S-56
In FUNC.LIST, rotate the Selector until D/R & EXP is
highlighted. Press the Selector to access the Dual Rate
and Exponential menu. Rotate the Selector to highlight
the channel (aile, elev or rudd) then press the Selector
to select the desired channel that you wish to adjust the
dual and expo rates for. Rotate to select then press the
Selector to store the desired channel.
Note: Three D/R and EXPO positions (values) are
available (Pos0, 1 and 2).
Under AUTO on the right of the screen, rotate the
Selector until
CRUI is highlighted and press the
Selector. Select
Pos1 as the active position for the
cruise mode by rotating the Selector and then pressing
the Selector when
Pos1 is highlighted. This will
automatically access dual rate and expo values that are
programmed into position 1 whenever the cruise mode is
selected. Now rotate the Selector to
Pos1 and depress
the Selector to highlight the D/R values. Rotating the
Selector changes these values. Displacing the aileron
stick right or left allows the dual rate to be independently
adjusted in each direction. Depress the Selector to store
the desired D/R values. Rotate the Selector to the
EXP
Pos1
values and adjust these values in the same manner,
pressing the Selector to store the desired value.
Now go back to channel and do the same thing for the two
remaining channels. Press the LIST button to return to the
Function Mode screen.
This function is normally not used in the cruise mode,
however, it is active and all trim adjustments will be
automatically stored when the cruise mode is selected.
D/R EXP
110% 30
110% 30
125% 30
125% 30
125% 30
125% 30
[D/R & EXP]◊0
POS-0
POS-1
POS-2
AILE
ELEV
RUDD
AUTO
CRUI:0
SPEE:1
THRM:2
[MONITOR]
CAMB
AILE RUDD ELEV FLAP FPRN
0 0 0 0 0CRU
0 0 0LAU
0 0 0LND
