Step #16 Dual Rate and Exponential
Step #17 Elevator-to-Flap Mix
S-51
In FUNC.LIST, rotate the Selector until D/R & EXP is
highlighted. Press the Selector to access the Dual Rate
and Exponential menu. Rotate the Selector to highlight
the channel (aile, elev or rudd) then press the Selector
to select the desired channel that you wish to adjust the
dual and expo rates for. Rotate to select then press the
Selector to store the desired channel.
Note that three
D/R and EXPO positions (values) are
available (Pos0, 1 and 2). Under AUTO on the right of the
screen, rotate the Selector until
LAUN is highlighted and
press the Selector. Select
Pos0 as the active position
for the launch mode by rotating the Selector and then
pressing the Selector when
Pos0 is highlighted. This
will automatically access dual rate and expo values that
are programmed into position 0 whenever the launch
mode is selected. Now rotate the Selector to Pos0
and depress the Selector to highlight the D/R values.
Rotating the Selector changes these values. Displacing
the aileron stick right or left allows the dual rate to be
independently adjusted in each direction. Depress the
Selector to store the desired D/R values. Rotate the
Selector to the
EXP Pos0 values and adjust these values
in the same manner pressing the Selector to store the
desired value.
Now go back to channel and do the same thing for the two
remaining channels. Press the
LIST button to return to the
Function Mode screen.
This function is normally not used in launch mode. It will
be addressed in setting up the Cruise mode below.
