TRVL ADJ. – TRAVEL ADJUST
A-21
Travel Adjust is used to adjust how far a servo travels in
each direction. After the linkages have been installed and
attached to the servos, adjust the amount of servo travel in
each direction. For more information on Servo Travel and
Mechanical Advantage, please refer to the Sub Trim Usage
and Mechanical Advantage article contained in the Glossary.
1. Highlight and select TRVL ADJ. in the FUNC.LIST
to obtain the Travel Adjust display.
2. Use the Selector to highlight and select each channel
and adjust the travel in each direction by rotating the
Selector. The direction of travel is changed by moving
the stick/switch/lever back and forth.
[TRVL ADJ.]
THRO L100% R100% GEAR +100% -100%
AILE L100% R100% FLAP U100% D100%
ELEV D100% U100% AUX2 +100% -100%
RUDD L100% R100% AUX3 +100% -100%
AUX4 +100% -100%
