X9303 2.4 USED AS SLAVE (STUDENT) – (Trainer System)
Timer
S-37
Highlight and select MASTER and the display will
switch to SLAVE. A message will appear instructing to
Connect DSC & POWER off. Make sure the transmitter
power switch is in the OFF position and the DSC cord is
connected between the 2 transmitters.
The X9303 2.4 is now ready to be used as the Slave
or student transmitter.
The X9303 2.4 contains a Timer System that contains
three timers. One is an integrated timer that keeps track of
total transmitter-on time for the model and it is displayed
on the Main display. The other timers can be configured
as Countdown timers or as a Stopwatches. This timer
also appears on the Main display when active and can be
started, stopped and reset from the Main display.
1. To configure the timer as a Countdown timer, highlight
and select
Timer in the FUNCTION LIST to obtain the
Timer display.
Highlight and select INH under TIMER and then select
DOWN-T. Use the Selector to set the countdown start
time. Once the timer is set, TIM will appear on the
Main display in the lower left corner. The timers can be
programmed to several different buttons or switches.
Use the Selector to highlight the desired button or
switch to operate the timer. Press the Selector to
confirm the selection.
2. To Reset the Integrated Timer, highlight and select the
time under
INTEG-T and Push [CLR]=0:00 appears
on the display. Press the CLR button to the left of the
display to reset the integrated timer.
