[Page 1] 5. TARGET (TGT) EXPANSION
• Expands a target to the display size.
• By expanding a target, the visibility of a small target is improved, thereby improving the sensitivity.
• However, if a target is expanded, the bearing and distance resolution deteriorate.
• The use of "EXP2" is recommended instead of "EXP1".
• The operation characteristics of the target expansion function are as follows.
OFF : The target expansion function is not used.
Use this mode when a high resolution is required.
EXP1 : Expands the target display size to the distance direction.
Expands also the bearing direction in the center of the screen.
Effective for searching small targets by using "PROC3".
Note that the screen may be filled with emphasized noise if "PROC2" is used
concurrently.
EXP2 : Expands the target display size to the vertical and horizontal directions.
Can be used regardless of the Video processing.
Use this mode when the sea clutter is strong.
EXP3 : Mode that sets "EXP1" and "EXP2" concurrently.
Use this mode for detecting small targets such as radio buoy.
Page 1
1. MODE (Select the name to be used)
2. PROCESS OFF PROC1 PROC2 PROC3
3. IR OFF IR1 IR2 IR3
4. AUTO STC/FTC OFF AUTO STC AUTO FTC
5. TGT EXPANSION OFF EXP1 EXP2 EXP3
6.
7.
8. SAVE PRESENT STATE
To Next Page
