3 – 67
3.4
[Page 4] 4. RADAR TRAILS PROCESS
• Select whether video processing is performed for radar signals to create a radar trail.
• When radar trails process is set to "ON", a radar trail may not be created due to clutter and noise and
a radar trail of the target moving at a high speed may not be created.
• When radar trails process is set to "OFF", a radar trail may be created by clutter and noise and a radar
trail of the target that moves at a high speed can be created.
OFF : Video processing is not performed for the radar signals that create a radar trail.
ON : Video processing is performed for the radar signals that create a radar trail.
[Page 4] 5. RADAR TRAILS SMOOTHING
• Select whether a radar trail is smoothed for display.
• When a radar trail is not continuous, the radar trail is smoothed by connecting the disconnected
sections when displayed.
• When radar trail smoothing is used, the radar trails become slightly thicker. Set smoothing to "OFF"
to make the radar trail finer.
• Since smoothing processing is performed at the display stage of a radar trail, the radar trail storage
data will not be changed. (When smoothing is set to "OFF" after it is set to "ON", the data is reset to
the original state immediately.)
OFF : Radar trails smoothing processing is not performed.
ON : Radar trails smoothing processing is performed.
Page 4
1. RADAR TRAILS INTERVAL 1MIN 3MIN 6MIN 12MIN
15MIN 30MIN 60MIN CONT
2. RADAR TRAILS REF LEVEL LEVEL1 LEVEL2 LEVEL3 LEVEL4
3. RADAR TRAILS REDUCTION OFF LEVEL1 LEVEL2 LEVEL3
4. RADAR TRAILS PROCESS OFF ON
5. RADAR TRAILS SMOOTHING OFF ON
To Next Page
