Soware features
Supports rate selectability at the port level.
By default, the ports are congured as 10-Gigabit Ethernet ports.
Opcal diagnoscs and related alarms.
Power requirements Line-rate throughput of 2.4 Tbps:
Power consumpon at dierent temperatures:
25° C: 1335 W
40° C: 1425 W
LEDs OK/FAIL LED:
Steady green—MPC is funconing normally.
Yellow—MPC has failed.
Port LED—Link
O—Port is not enabled.
Green—Port link is up with no alarms or failures.
Red—Port link is down with alarms.
NOTE: When a QSFP+ port is congured for the 10-Gigabit mode with a breakout cable, the link status for the 10-
Gigabit port is indicated with the addion of four LEDs provided on the line card. The lane LEDs for the
corresponding port indicates the port status.
Like the port status LED, each individual lane LED supports four states as: OFF, AMBER, GREEN, RED. See MPC
and MIC Lane LED Scheme Overview for more details.
For the 40-Gigabit mode the lane number LED is not applicable. The port LED indicates the port status, irrespecve
of whichever lane number LED is ON.
Cables and
connectors
TIP: You can use the Hardware Compability Tool to nd informaon about the pluggable transceivers supported
on your Juniper Networks device.
The list of supported transceivers for the MX Series is located at MX Series Supported Transceivers.
69
