6-7
Technical requirements and instructions
Top up to norm the oil level in
the vehicle hydraulic system
(for hydraulically operated ve-
hicle).
The oil level should be in the in-
spection hole middle (see. Fig. Hy-
draulic oil tank).
If necessary, add oil through the
filling neck.
Greases are used in accord with
suggestions of Appendices 2, 3.
Check the state and cottering
of pins of auxiliary brake air
cylinder.
Cylinder and rod must be secured and cottered.
It is not permissible to use parts without cotters and with excessive play.
Hydraulic oil tank of the vehicle
1
- hydraulic oil tank; 2 - inspection hole;
- filling neck
