Maintenance
6085 758 102b - 2006-10
40
4.7 Oil Fill
After an oil change
Open oil overflow plug (4).
Fill in oil at position 9.
For tightening torques refer to table on pages 45 and 46.
Undertake test run: Distance of 2-5 km.
End of test run:
Vehicle stationary. Do not engage Intarder. Open oil overflow plug (4).
CAUTION
Check oil level again and if necessary, top up with oil until it overflows.
Screw oil overflow plug (4) back in with new sealing ring.
Fill transmission until oil overflows.
Screw oil overflow plug (4) back in with new sealing ring.
Test run:
Do NOT engage Intarder.
Test run:
At beginning, actuate Intarder ONCE, BRIEFLY (max. step)
and then, set it back to step 0.
Screw in oil filler plug (9) with new sealing ring
.
NOTES
The transmission and fitted Intarder may only be filled with oil when the vehicle is
horizontal and the engine is switched off. Drain oil. For oil grade and volume refer to table on pages 45 and 46.
or after repairs
Open oil filler plug (9).
