1)
Reference value (depends on vehicle type and vehicle data as well as
the prevailing operating conditions).
2)
To this end, also observe the ZF guidelines for installing manual
transmissions (1203 765 110).
3)
To a large extent, the connection for the turning-shaft shift control
can be adapted to the vehicle’s installation conditions.
4)
Option
5)
For the required air pressure, observe the ZF guidelines for installing
manual transmissions (1203 765 110).
6)
Transmission inclination: 0 to 3°.
for standard drive
Transmission type Direct drive 16 S 1620 TD 16 S 1920 TD 16 S 2220 TD 16 S 2320 TD –
Overdrive 16 S 1820 TO 16 S 2220 TO 16 S 2520 TO – 16 S 2723 TO
Input torque max. Nm
1)
1600 / 1850 1900 / 2200 2200 / 2500 2300 2700
Ratios of Forward gears TD = 16.41 - 1.00 TO = 13.80 - 0.84
Reverse gears TD = 15.36 - 12.92 TO = 12.92 - 10.80
Speedometer electronic z = 6
Installation
2)
horizontal with integrated clutch housing to the left
Shift system 4-speed section forward gears synchronized; reverse gear with constant-mesh
Range change
and splitter group synchronized
Shift actuation 4-speed section via horizontal turning-shaft shift control
3)
with superimposed H shift patternor
double H shift pattern
4)
Range change Superimposed H: changeover effected by means of the preselector switch at the
group
5)
shift lever. Double H
4)
: changeover effected independently, triggered by the
respective selector motion
Splitter group
5)
pilot valve at shift lever
Weight
(without additional equipment) approx. kg 289 315 319 334
Oil quantity for standard install.
6)
approx. l 11 13 13 13.5
for oil change approx. l 8 10 10 11
Oil grade according to applicable ZF List of Lubricants TE-ML 01 or TE-ML 02
6
1341 758 101 - 2012-05
Technical Data
