2.4 Auxiliary power units
Depending on the vehicle version, Ecosplit transmissions can
be equipped with the following auxiliary power units (Fig. 5):
• Separate heat exchanger
for cooling the transmission oil
• Voith and Telma retarder
can be built in upon request
Fig. 5
Description
Torque con-
verter clutch
+ PTO
Engine-
dependent
PTO
NMV 221
Integrated
ZF-Intarder
Drive-
dependent
PTO
N ... PL
Clutch-dependent
PTOs
N1, N4, and N10
011359
