6-8
WEEKLY MAINTENANCE (WEEKLY MNT.) PROCEDURES
Description of procedure
Technical requirements and instructions
Check the cotter-pinning of
nuts of steering rod ball pins
(visually), the fastening of pit-
man arm.
The pitman arm should not have any damages. The nut to fasten the pitman
arm should be secured and locked with a plate. The nuts of steering rod ball pins
should tightened and cottered. If there are no cotters put them on their place.
Inspect condition and operation
of hydraulic locks and hydrau-
lic cylinder for rais
lowering the cab.
The locking mechanism must retain the cab securely from
spontaneous raising. Check the spring for integrity Check visu-
ally the locking device - worn rods and hook mouth are not
permitted.
The hydraulic cylinder for raising and lowering the cab
should be securely fastened. It is not permissible to use parts
without cotters.
Check the cotter-pinning of nuts of steering rod ball pins
of hydraulic cylinder
for raising and lowering
