7-31
Fuses
Symbol Rating Consumer
State of the main supply switch/
ignition switch key
FU1.1
5A
EFU control unit
ON
FU1.2
5A
Air suspension control module
ON
FU1.3
5A
Control module for electric equipment (CBCU)
ON
FU1.4 5A EBS control unit ON
FU1.5
5A
ADM3 engine control unit
ON
FU1.6
10A
Control unit for after-treatment system
ON
FU1.7 10A Control unit for MR2 engine ON
FU1.8
10 А
Control unit for gearbox
ON
FU1.9
10A
Retarder control unit*
ON
FU1.10 5A OBD-diagnostics connector ON
FU1.11
5A
Tachograph / instrument cluster
ON
FU1.12
5A
Connector for special add-ons
ON
FU2.1 5А Electronic control unit gVCU ON
FU2.2
10A
Driver's side control panel
ON
FU2.3
10А
Dehumidifier
ON
FU2.4
5A
Alternator exciting coil
ON
FU2.5
5A
Control module for central lock
ON
FU2.6
20А
Voltage converter 24/ 12V
ON
________________________
* For certain configurations
