7-34
Symbol Rating Consumer
State of the main supply switch/
ignition switch key
FU5.7
20A
Control module for electric equipment (CBCU) gr.1
Is not dependent/0
FU5.8
20A
Control module for electric equipment (CBCU) gr.2
Is not dependent/0
FU5.9
20A
Control module for electric equipment (CBCU) gr.5
Is not dependent/0
FU5.10
20A
Control module for electric equipment (CBCU) gr.6
Is not dependent/0
FU5.11
25A
engine liquid heater
Is not dependent/0
FU5.12
Is not dependent/0
FU6.1
15A
Control module for electric equipment (MUX4-P)
Is not dependent/0
FU6.2
15A
Control module for electric equipment (MUX4-P)
Is not dependent/0
FU6.3
15A
Control module for electric equipment (MUX4-P)
Is not dependent/0
FU6.4
15A
Control module for electric equipment (MUX4-P)
Is not dependent/0
FU6.5
15A
Control module for electric equipment (MUX4-P)
Is not depend ent/0
FU6.6
15A
Control module for electric equipment (MUX4-P)
Is not dependent/0
FU6.7
15A
Seat heater
ON
FU6.8
5A
Monitoring system/ ERA-GLONASS
ON
FU6.9
15A
Control module for central lock
ON/0
FU6.10
10А
Air heater (boi ler)*
ON/0
FU6.11
Air heater (timer)*
ON/0
FU6.12
5A
Monitoring system/ ERA-GLONASS
ON/0
________________________
* For certain configurations
