7 - pressure gauge in brake system circuit 1;
the rated air pressure in pneumatic drive is from 9,0
to 10,0 kgf/cm
2
. Pilot lamp is located in the indicator
zone
, and it lights up (color - red) when pressure
drops in the 1-st brake system circuit;
8 - pressure gauge in the 2-nd brake system cir-
cuit; the rated air pressure in pneumatic drive is from 9,0
to 10,0 kgf/cm
2
. Pilot lamp is located in the indicator
zone
, it lights up (color - red) when pressure drops in
the 2-nd brake system circuit;
9 - liquid temperature gauge in cooling system.
Over temperature pilot lamp is located in the indicator
zone
, it lights up (color - red) at over temperature of
cooling liquid;
10 - tank fuel level indicator.
Fuel reserve pilot lamp is located in the zone of in-
dicator
, it lights up (color – orange), when fuel amount
decreases in in the tank till 12 % of the tank volume;
11 - shift button of total number of kilometers
travelled/ «resettable» mileage. At short pressing of the
button, the mode changes. At pressing of the button more
than 3-5 sec. the mileage is reset;
12 - screen scrolling button
(doubler of the button
on the steering wheel).
Attention!
Steady operation of instrument cluster is guar-
anteed at ambient air temperature to – 40 ºС.
At ambient air temperature lower than -30 ºС
wrong displaying of information is possible.
