Keysight N9927-90001 User’s Guide 251
RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only)
Record/Playback (RTSA Option)
— New Session OR
— Recall Session
then Open and select a session.
—Then Recorder Player
—Then Record
REC is displayed in the left of screen graticules.
During recording, choose from the following:
— Pause Resume
Temporarily halts recording until pressed again. The
incoming trace continues to sweep. Press again to continue recording.
— Stop
Immediately stops recording. Then choose from the following:
—Press Play
to start replaying the recording from the beginning.
—Press Record
to continue recording.
— User Tag
Press to insert a User Tag at the current recorded trace. This
allows you to quickly move to this location during playback. Learn more in
About State and User Tags in “About State and User Tags” on page 249.
How to Playback a Session
—Press Trace 6
— If the session is already open, skip the following step. Otherwise:
—Then Record Playback Setup
—Press Recall Session Then select a session to playback and press
Open
.
—Then Recorder Player
—Then Play
PLAY is displayed in the left of screen graticules during playback. When the
end of the recording is reached, playback begins again at trace 1 and
continues to loop indefinitely.
During playback, choose from the following:
— Pause Resume
Temporarily halts playback. Then choose from the
following:
— Pause Resume
Press to continue playing.
If these are large recordings on a device, it could take several seconds for
the FieldFox to display the list.
