178 Keysight N9927-90001 User’s Guide
SA (Spectrum Analyzer) Mode
SA Mode Settings
— 101 | 201 | 401 | 601 | 801 | 1001
— # Points to enter a trace points value manually (Maximum = 20001).
Trace Display States (SA Mode)
In SA Mode you can display up to four of the following types of trace states. All
SA settings are applied to all displayed traces. See also “Marker Trace (IQA
and SA Mode)” on page 602.
A color-coded legend for displayed traces is visible in the left pane of the SA
mode screen:
W = Clear/Write; M = MaxHold; m = MinHold; A = Average; V = View
How to display the Trace States
—Press Trace 6.
—Then Trace 1,2,3,4
repeatedly to select a trace number to display or change
its state. Traces are displayed in the following colors:
—Trace 1 – Yellow Trace 2 – Blue
—Trace 3 – Orange Trace 4 – Green
—Then State [current setting]
— Then choose from the following Trace States:
—Clr /Wr
(Clear/Write) Displays the actual measured data for each
sweep.
—MaxHold
Displays the maximum response of the input signal at each
data point over multiple sweeps. See also Average Count in “Average
Count” on page 180.
—MinHold
Displays the minimum response of the input signal at each
data point over multiple sweeps. See also Average Count in “Average
Count” on page 180.
—Average
Each data point is averaged over multiple sweeps as set by
the Average Count setting. Learn more in “Average Count” on
page 180.
—View
Displays and then holds the last complete measurement trace on
the screen. This is similar to storing a trace in memory.
—Blank
Displays no trace.
